Product Overview

The 90-degree chain plate bucket elevator is a space-saving automatic conveying system designed for modern food packaging lines.

With a vertical 90° structure, it significantly reduces factory floor space while ensuring stable and continuous material feeding to packaging machines such as multihead weighers and vertical packing machines.

Compared with traditional belt elevators, this chain plate design provides stronger stability, lower maintenance cost, and better performance for fragile and frozen products.

Key Advantages

1. 90° Vertical Space-Saving Design

This machine adopts a true 90-degree vertical lifting structure, greatly saving workshop space and allowing flexible layout in limited production areas.

2. Hook Chain Plate Anti-Falling Design

The special hook-type chain plate structure ensures materials do not fall or scatter during high-angle conveying, especially suitable for lightweight and fragile products.

3. Modular Chain Plate – Low Maintenance Cost

If a chain plate is damaged, only the broken section needs to be replaced.
No need to replace the entire belt like traditional belt conveyors, greatly reducing long-term maintenance cost.

4. Food Grade Hygienic Design

Made of stainless steel structure with easy-cleaning design, fully meeting food industry hygiene requirements.

5. Perforated Chain Plate for Drainage

The chain plates are designed with holes, allowing water drainage and preventing water accumulation, making it ideal for frozen food and washed products.

6. Combines Advantages of Z-Type & Belt Conveyor

This machine integrates the stability of a Z-type bucket elevator and the flexibility of a belt conveyor, achieving:

• Stable lifting
• Low product damage
• High efficiency feeding
• Wide application range

Applications

Suitable for:

• Potato Chips
• Popcorn
• Puff Snacks
• Frozen Blueberry
• Frozen Strawberry
• Frozen Vegetables
• Frozen French Fries
• Breakfast Cereal
• Pet Food
• Granules and Lightweight Products

Working System Integration

This machine can be connected with:

• Multihead Weigher
• Linear Weigher
• Vertical Form Fill Seal (VFFS) Machine
• Packaging Production Line

It provides automatic and continuous feeding for high-efficiency production systems.

Why Choose Our Chain Plate Elevator?

✔ Space-saving 90° design
✔ Lower maintenance cost than belt conveyor
✔ Suitable for fragile and frozen products
✔ Easy cleaning structure
✔ Stable feeding for high-speed packaging lines
✔ Custom height and bucket size available
✔ Export standard (USA / EU market)
