Semi-automatic Beef Jerky Packing Machine with Multi-head Weigher
Application
It is suitable for weighing and packing grain, stick, slice, globose, irregular shape products such as candy, chocolate, jelly, pasta, melon seeds, peanuts, pistachios, almonds, cashews, nuts, coffee bean, chips and other leisure foods, raisins, plum, cereals, pet food, puffed food, fruits, roasted seeds, sea food, frozen food, small hardware, etc with pre-made bag.
Specification
| Model | ZH-BR10 |
| Packing speed | 15-35 bags/min |
| System output | ≥4.8 Ton/day |
| Packing accuracy | ±0.1-1.5g |
Features
1. Material conveying, weighing are completed automatically.
2. High weighing precision and material drop is controlled by manual with low system cost.
3. Easy to upgrade to automatic system.
System Construction
| Z type hoister: Raise material to multihead weigher which controls the start and stop of the hoister. |
| 10 heads multi weigher: Used for quantitative weighing. |
| Platform: Support the 10 heads multi weigher. |
| Timing hopper & feeding tube: Used as the buffer for material and is easy for using bag manually. |
