Full Automatic Vertical Coffee Beans/Peanut/Cashew Nut Granule Packaging Machine
The Most Cost-Effective Choice: Low Cost But High Yield
Small Sachet Packing Machine
ZON PACK automatic small sachet packing machine is designed for small cost granule packaging machine with low budget. Stable operation, good pouch appearance, and accurate weight.
Application
Solid material which shape is roll, grain or slice. Such as puffed food, shrimp slice, peanuts, popcorn, chocolate, seeds, oatmeal, coffee, white sugar, electuary and solid beverage etc.
Main Feature
1. High precision, high efficiency without crash the materials.
2. Full automaticity. The machine complete the whole procedure of feeding, measuring, bagging, date printing, charging, product out put automatically.
3. High sensitivity photoelectric eye color tracing, numerical input of cutting sealing position for extra accuracy.
4.All the works of bag making,measuring,filling,sealing,cutting and counting can be done automatically, at the same time, it can also according to the demand of customers printing batch number and other functions.
5.The touch screen operation, PLC control, drive stepper motor to control the bag length, stable performance, easy to adjust and accurate detection.
6.Packing material：BOPP/Polyethylene, Aluminum/Polyethylene, Paper/Polyethylene,
Polyester/Aluminizer/Polyethylene, Nylon/CPP and so on.
|
Technical Parameter |
|
| Model | ZH-300BK |
| Packing speed | 30-80 bags/min |
| Bag Size | W: 50-100 mm L: 50-200 mm |
| Bag Material | POPP/CPP,POPP/VMCPP,BOPP/PE,PET/AL/PE, NY/PE,PET/PET |
| Max Film Width | 300mm |
| Film Thickness | 0.03-0.10 mm |
| Power Parameter | 220V 50hz |
| Package Size (mm) | 970(L)×870(W)×1800(H) |
Machine details
If you are interested in our machine, please send us your detailed requirements:
1. Products/ Characteristic
2. Weighing Range
3. Bag Size/ Packing Material
4. Bag Type
