1. Technical Description
Food grade gold detector can be used to detect food raw materials and packaged products, and can automatically remove metal substances such as iron and stainless steel
2.Main Features
1. Detector is made by hard filling technology with better stability.
2. Multiple optional exclusion mechanisms that can automatically remove non-conforming products;
3. The human-machine interface is user-friendly, easy to operate, intuitive and convenient;
4. 100 sets of product parameters can be set, and production data can be statistically analyzed and output via USB;
5. Equipped with automatic parameter adjustment function, input product parameters and weighing requirements to automatically complete parameter settings;
6. Compact design, saving space and installation costs.
3. Product Specifications
| Index |
Parts |
Description |
| 1 |
Material of Frame |
SUS304 |
| 2 |
Weighing range (g) |
3~4000 |
| 3 |
Minimum scale (g) |
0.1 |
| 4 |
Accuracy (g) |
±0.5 |
| 5 |
Size of detector frame (W*H) mm |
360*150 |
| 6 |
Metal sensitivity |
Fe≥1.0, NF≥1.5,SUS304≥2.0 |
| 7 |
Max throughput (pcs/min) |
80 |
| 8 |
Size of weighing belt (W*L) mm |
360*550/650 |
| 9 |
Height of conveyor belt (mm) |
700~820*780~900 |
| 10 |
Length of machine (mm) |
1200-550*650-1200 |
| 11 |
Parameter setting |
Auto setting by intelligent product study |
| 12 |
Direction of throughput |
From left to right when facing control panel |
| 13 |
Alarm mode |
Aural and visual |
| 14 |
Reject device |
Air jet, air pusher, down belt, flipper |
| 15 |
Power |
AC 220V 1Phase, 200W, 50/60 Hz adaptive |
| 16 |
Working environment |
Free of obvious vibration, high power frequency converter and large moving metal piece |
