Automatic Sugar Chocolate Packaging Line System Vertical Candy Packing Machine
Applications
The bag packing machine is suitable for packaging of soft pouch powder , Packing material include several kinds of heat-seal
lamination, such as PET/plated AL/PE, PET/PE, NYLON etc.
Features
* Computerized touch screen, easy to adjustments and operation, and easy to change products, with exception appearance
system,easily and rapidly to repairing;
* Could be automatically to finish making bags, sealing, printing, and optional functions
* Design with alarming for door unclosed, no rolled film etc;
* The advanced design ensures that it is very convenient for adjustment, operation and maintenance when different profession use;
* It can support the use of a variety of automatic metering equipment at home and abroad
System unite
1.Z type conveyor/Incline conveyor
2.Multihead weigher
3.Working Platform
4.VFFS
5.Finished bags conveyor
other options:
6.Check weigher/Metal detector
7.Rotary table
Technical Specification
|
Model
|
ZH-BL10
|
|
System Output
|
≥ 8.4 Ton/Day
|
|
Packing speed
|
30-70 Bags / Min
|
|
Packing Accuracy
|
± 0.1-1.5g
|
|
Bag size(mm)
|
(W) 60-200 (L)60-300 for 420VFFS
(W) 90-250 (L)80-350 For 520VFFS
(W) 100-300 (L)100-400 For 620VFFS
(W) 120-350 (L)100-450 For 720VFFS
|
|
Bag type
|
Pillow bag, standing bag (gusseted), punch, Linked bag
|
|
Range of measuring (g)
|
5000
|
|
Thickness of film (mm)
|
0.04-0.10
|
|
Packing Material
|
laminated film such as POPP/CPP, POPP/ VMCPP, BOPP/PE,
PET/ AL/PE , NY/PE, PET/ PET,
|
|
Power Parameter
|
220V 50/60Hz 6.5KW
|
