Automatic Cardboard Carton Sealer Box Tape Sealer Machine
Machine Description
This carton sealing machine is mainly used in sealing and packing cartons, which can be work with strapping machine or as a necessary part of a production line.
We have different models of carton sealing machines that can work for cartons of different sizes. We accept custom machines and customize machines according to the size of your carton. If needed, please contact us！
Multiple sealing methods are available to meet your needs
|
Technical Specification
|
||||
|
Model
|
ZH-GPA-50
|
ZH-GPC-50
|
ZH- GPE-50P
|
|
| Convying Speed | 18m/min |
18m/min
|
18m/min | |
| Carton Range |
L:150mm W:150-500mm H:120-500mm
|
L:200-600mm W:150-500mm H:150-500mm | L:150mm W:180-500mm H:150-500mm | |
| Voltage Power | 240W 110/220V 50/60HZ 1 Phase | |||
|
Tape Size
|
48/60/75mm
|
|||
| Mesa Height |
600mm+150mm
|
|||
| Machine dimensions | L:1020mm W:850mm H:1350mm（Excluding front and rear roller frames) | L:1770mm W:850mm H:1520mm | L:1020mm W: 900mm H:1350mm | |
| Weight | 130kg | 270kg | 140kg | |
Details Images
Left and right + up and down driven carton sealer adopts sticky tape to seal the carton, which can complete the top and bottom sealing actions at one time, and the sealing effect is neat and beautiful. At the same time, the width and height can be adjusted independently according to the size of the carton, and printing tape can also be used to improve the product image. This case sealer is lightweight and equipped with swivel casters for flexible movement. This box sealing machine is widely used in various industries at home and abroad such as food, medicine, toys, tobacco, daily chemicals, electronics and so on.
Machine Structural Features
The width and height can be adjusted manually according to the carton specifications,and the operation is simple and convenient
The conveyance belt with strong friction force is adopted,the material is thick and durable,and the conveyance is stable
Durable,no rust,good bearing capacity
Use cost-effective power control panel,and the serivice life of key control can reach 10000 times
Application Materials
automatic carton sealer machine with both side deive in close all four top case flaps ,use the handle to adjust wideth and height,the structure design of the high strength makes the machine has reliable performance and can be adapted to production line continuous heavy sealing work .IT is suitable for packing and sealing of products in various industries such ad household applicances ,textile ,food,daily provisions,medicine,light industry ,chemical industry and so on.
